Technicial Parameters

Single-Module Specification

No.

Name

H

W

1

Pixel Distance

3.91x7.8mm

2

LED Type

SMD1921

3

Module Resolution

128dots

16dots

5

Pixel Density

32768 dots /m2

6

Average Power

320W/ m2

7

Max. Power

800W /m2

Screen Specification

1

Box Size

1000mm*500mm

2

Display Resolution

256*64

3

Brightness

4500mcd /m2

4

Light Transmittance

60%

5

Visual Angle

H 140°        V 120°

6

Best Visual Distance

6m

7

Grayscale

Red, Green, Blue or 256 level

8

Refresh Rate

>1920

9

Frequency Change

50 -- 60Hz

10

Input Voltage

AC220V/50Hz or AC110V/60Hz

11

Dead Rate

<0.1%

12

Power Consumption

320W /m2 max;          800W /m2 Min

13

Average No-Malfunction Hours

>10,000 hours

14

Lifetime

50000 hours

15

Light Dissipation

<3%

16

Leakage Current

<3mA

17

IP Grade

IP20

18

Storage Temperature

40°C–60°C

19

Storage Humidity

10%–95%

20

Master Controlling System

Novastar

21

Supporting Systems

Windows XP/W7/Vista /W10/ W11
