Model:  BL-LNS1020C60-S series

Features:   Dimension:
Produced with Samsung 2835 LED


Side-viewing light, Flat shape
Double-layer structure design, No dot lights
With double-color silical gel co-extrusion molding technology
Easy cutting with clear side-cutting-line design
Excellent heat-dissipation performance
With high-quality silical gel, No softening & yellowing
5 Years Warranty
UV Resistant
Packed in 5 meters per roll

Order Information:
Code No.LEDs/m Watt/m Luminus Flux
(lm/m) 		Voltage CCT CRI (Ra) Cuttable (mm) Beam Angle IP Rating
BL-LNS1020W60-65-S
120
10W
>650
12V DC
6500K   Samsung
80+
25
180°
IP 67
BL-LNS1020W60-50-S
120
10W
>650
12V DC
5000K   Samsung
80+
25
180°
IP 67
BL-LNS1020W60-40-S
120
10W
>650
12V DC
4000K   Samsung
80+
25
180°
IP 67
BL-LNS1020W60-30-S
120
10W
>650
12V DC
3000K   Samsung
80+
25
180°
IP 67
BL-LNS1020R60-S
120
10W
12V DC
Red
80+
25
180°
IP 67
BL-LNS1020G60-S
120
10W
12V DC
Green
80+
25
180°
IP 67
BL-LNS1020B60-S
120
10W
12V DC
Blue
80+
25
180°
IP 67
BL-LNS1020Y60-S
120
10W
12V DC
Yellow
80+
25
180°
IP 67
BL-LNS1020O60-S
120
10W
12V DC
Orange
80+
25
180°
IP 67
BL-LNS1020PK60-S
120
10W
12V DC
Pink
80+
25
180°
IP 67
BL-LNS1020PP60-S
120
10W
12V DC
Purple
80+
25
180°
IP 67
